New Steel housing cone fan 52”



Due to the fact that tunnel-ventilated houses are growing in size and complexity, there is an increasing demand for more powerful, reliable and energy-efficient exhaust fans. The BF Agromax cone fan is a 52” fan exhaust cone fan has been especially designed to fulfil that demand. This fan is the ideal fan for high airflow capacity at high static pressures and low energy consumption. The unique propeller design is self-cleaning and allows the highest efficiency to be reached. The square fan housing, the discharge cone, shutter blades and the air-conveyor (Venturi) are made of galvanized steel sheet.



The 4-blade propeller is statically and dynamically balanced, resulting in low vibration and low noise level during operation. The propeller is attached to the central pulley, which comprise - together with the V-belt and electrical motor - the belt drive system. As part of the design of the outlet it is composed of 4 cone sectors which can be assembled on-site to form the complete discharge cone. The shutter blades placed on the inlet side are operated by the centrifugal opening device.
